3X7 Feet 1 Hour Fire Rated Metal Doors With Glass/ Dark Gray/ Powder Coated Finish
Steel Insulated FD60 Fire Door
Product Description
steel fire door is widely used in all kinds of public fire -proof areas because of its solid structure, simple shape and beautiful surface. Inlaid with fire -proof expansion sealing pieces, the door frame is made of high quality galvanized steel strip, which is one-time rolled and formed through the special production line, without impact sound when closing. Beams are connected with mullions by 90° angle welding, and the large size door frame can be assembled with bolts. The door leaf adopts the process that high-quality cold-rolled galvanized steel sheet is bent by the bending machine precisely, and its interior is filled with green and perlite board which has characters of fireproof, heat & sound insulation and its surface adopts technology without welding spots, so that to get smooth appearance.
Features
1. Insulation and fire prevention. All the products get through the international inspection, and we can provide fire doors with fire resistance level of A1.50, B1.0 and C0.50. All of our products are Class A;
2. Filled in high refractory and heat-insulating material to ensure life safety;
3. Thickening and reinforcement, solid construction, stable bearing and impact resistance;
4. There is no soldering point on the surface of the product, which is easy to disinfect and clean;
Parameters
| Product Name | Regular Steel Fire Door |
| Fire Rating | 30 min/60 min/ 90min/120min |
| Certificate | CCC, ISO9001:2008; UL; BS |
| Material of Door Leaf | Galvanized Steel Sheet |
| Material of Door Frame | Galvanized Steel Sheet |
| Thickness of Steel Sheet of Door Leaf | 0.8 mm |
| Thickness of Steel Sheet of Door Frame | 1.2 mm |
| Thickness of Door Leaf | 120min: 55 mm 90min: 55 mm 60min: 45 mm 30min:40 mm |
| Frame Depth | 120min:55 mm 90min: 120 mm 60min: 112 mm 30min: 90 mm |
| Open Style | Swing Open, Left Handed, Right Handed |
| Infilling Material | 90min: 53 mm Fireproof Perlite Board(400±40kg/m3) 60min: 43 mm Fireproof Perlite Board(300±30kg/m3) 30min: 38 mm Fireproof Perlite Board(300±30kg/m3) or Honeycomb Paper |
| Surface Treatment | Powder Coating Primer Paint |
| Color | RAL Colors or Customized |
| Glass | Single Open: 24mmX 350mmX 600mm Double Open: 32mmX 350mmX 600mm Or customized As Request |
| Fireproof Seal Strip | 90min: FPJ-B-20X 2 60min: FPJ-A-15X 2 30min: FPJ-A-15X 2 Or Customized |
| Hardware | High Quality Fire Lock, Fire Bolt, Fire Hinge, Fire Sequencer, Fir Door Closer and Others as Request |
| Warranty | 2 years |
| Package | Inside Bubble Bags with Outside Wooden Frame |
| Delivery Time | 35Days After Payment Received |
Hardware:
Generally our quotation will cover the cost for fireproof locks, hinges, bolts and closers. It won’t be extra fees unless you also demand others such as panic bars, door selectors and so on.
Besides, we can also transfer you all test reports and certificates of hardware.
Accessories
We paste around the door leaf perimeter fireproof expand smoke intumuscent which can stop flames and smoke from spreading through gaps between door leaf and frame. The sizes of intumescent stripes are normally FPJ-B-25X2mm and FPJ-B-20X2mm.
Other than smoke intumuscent we also customize door handles, push plates, door stoppers and others for you.
